Power your solar projects with the advanced Tata Power Solar Systems Limited TP540HG10B Glass-Glass bifacial solar module, engineered for high performance, long-term reliability, and superior energy generation. Built with Mono PERC bifacial technology and a durable double-glass architecture, this DCR-compliant solar module is ideal for residential, commercial, and industrial solar installations.
Designed for higher yield and better long-term returns, the TP540HG10B series offers power variants from 530W to 550W, with module efficiency up to 21.29% and positive power tolerance of 0 to +5W, ensuring better real-world generation performance. The bifacial technology allows rear-side energy generation for improved total output.
Built in India with Tata Power Solar’s advanced manufacturing standards, the module features a heavy-duty anodized aluminium frame, IP68 junction box, PID resistance, and strong mechanical load capacity, making it suitable for harsh environmental conditions.
Key Features
✔ DCR (Domestic Content Requirement) compliant
✔ Mono PERC bifacial technology
✔ Double glass (2mm + 2mm) construction
✔ 144 half-cut cells
✔ Up to 21.29% efficiency
✔ Positive power tolerance (0 to +5W)
✔ Better low-light performance
✔ PID resistant module
✔ Heavy-duty aluminium frame
✔ IP68 junction box protection
Technical Highlights (540W Variant)
- Rated Power: 540W
- Module Efficiency: 20.90%
- Open Circuit Voltage (Voc): 49.50V
- Maximum Voltage (Vmpp): 42.45V
- Maximum Current (Impp): 12.72A
- Short Circuit Current (Isc): 13.23A
- Maximum System Voltage: 1500V
- Dimensions: 2278 × 1134 × 35 mm
- Weight: 33 kg
Warranty
- 12 Years Product Warranty
- 30 Years Linear Performance Warranty
- Low annual degradation of 0.6%
Applications
- Residential rooftop solar
- Commercial solar projects
- Industrial installations
- Government subsidy projects
- EPC projects
Note
Available wattages may vary depending on stock and production batch. Exact model and wattage will be confirmed with the customer before dispatch.
